Scanner information

Category: A4
Name: KV-S2087
Catalogue: HERE

HIGH-SPEED FULL-COLOR SCAN

This speeds up the job of turning even large amounts of daily forms and mountains of documents into data. Clean, crisp, clear scanned data is also ideal for electronic file conversion and management.

* Free First Year Support and Maintenance

SPECIFICATIONS

Dimensions (approximate) (W x D x H)	350 mm x 319 mm x 242 mm (13.78 in. x 12.56 in. x 9.53 in.) * Protruding parts not included
Feed Tray capacity	Up to 200 sheets 80 g/m2(21 lbs., A4 or Letter) High-quality woodfree paper
Scanning Face	Duplex scanning
Scanning Resolution*1	ICP/TWAIN	50 – 600 dpi (1 dpi step) 1,200 dpi (Interpolated) Optical: 300 dpi / 600 dpi (Automatic switch)
	ISIS	100 – 600 dpi (1 dpi step) 1,200 dpi (Interpolated) Optical: 300 dpi / 600 dpi (Automatic switch)
Binary Speed*2Portrait, 200 / 300 dpi (A4)	Simplex	85 ppm
	Duplex	170 ipm
Color Speed*2Portrait, 200 / 300 dpi(A4)	Simplex	85 ppm
	Duplex	170 ipm
Feed Tray capacity	Up to 200 sheets 80 g/m2(21 lbs., A4 or Letter) High-quality woodfree paper
Interface	USB 2.0

*1 When scanning a document larger than A5 size at high resolutions over 600 dpi, the scanning may fail due to insufficient memory. 50 – 99 dpi can be used only when scanning with Image Capture Plus, TWAIN, or ISIS (ICP: Ver.3.12.1.1 or later, TWAIN: Ver.20.0.0.3 or later). *2 The scanning speed differs depending on the host computer, the operating system, the application, the measuring method, the quantity of data in the image, and the paper type. The scanning speed depends on a measuring method of Panasonic. *3 "Weight in pounds" of paper represents the weight of 500 (432 x 559 mm / 17 x 22 inches) sheets. *4 Dimensions and weight are approximate. *5 The power requirement differs depending on the country/area. *6 Presto! PageManager and Presto! BizCard are either registered trademarks or trademarks of NewSoft Technology Corporation in the United States and / or other countries. *7 The edition of Presto! PageManager 9 included with this unit is different to the commercially available one.
