Scanner information

  • Category: A3 and A4
  • Name: KV-S5078Y
  • Catalogue: HERE

Excellent performance keeps ofiice productivity high

This speeds up the job of turning even large amounts of daily forms and mountains of documents into data. Clean, crisp, clear scanned data is also ideal for electronic file conversion and management.

* Free First Year Support and Maintenance

SPECIFICATIONS

Dimensions (W x D x H) 468 x 444 x 344 mm (18.5 x 17.5 x 13.5 in.)
Scanning Face Duplex
Scanning Resolution*1 50 dpi - 600 dpi (1 dpi step)
and 1,200 dpi(interpolated)*2
Optical: 300 / 600 dpi (Automatic switch)
Humidity 20 % RH to 80 % RH (No dewdrop)
Binary Speed*2 Landscape, 200 / 300 dpi (A4) Simplex 120 ppm
Duplex 240 ipm
Color Speed*2 Landscape, 200 / 300 dpi(A4) Simplex 120 ppm
Duplex 240 ipm
Feed Tray Capacity 330 sheets: 80 g/m² (21 lbs.) High-quality woodfree paper (size: A4, A3)
*1 When scanning a document larger than A5 size at resolutions over 600 dpi, the scanning may fail due to insufficient memory. *2 50 – 99 dpi and 1200 dpi can be used only when scanning with Image Capture Plus, TWAIN, or ISIS. *3 The scanning speed is the maximum speed of the scanner hardware. It does not include software processing time, data transfer time, etc. The scanning speed measurement is based on Panasonic's measuring method. In case of using this unit with a LAN connection, the scanning speed may be slower due to network traffic. *4 "Weight in pounds" of paper represents the weight of 500 sheets (17 in. x 22 in. / 432 mm x 559 mm) *5 To assure continued emission limit compliance, use only shielded LAN cable. The cable should be a CAT 5 (Category 5) or higher for 10Base-T / 100Base-TX, or CAT 5e (Enhanced Category 5) or higher for 1000Base-T. *6 The power requirement differs depending on the country/area. *7 If connected to a network device (hub, router, etc.) that supports IEEE802.3az. *8 Available only when connecting via USB. *9 Required to installing OCREngine for Image Capture Plus on 2 or more PCs. (For 1 license) *10 Required to installing OCREngine for Image Capture Plus on 2 or more PCs. (For 10 licenses) *11 To install the scan server, you need this option. *12 Extend the maximum number of fields for zone OCR in Image Capture Plus from 3 to 10. (For 1 license) *13 Extend the maximum number of fields for zone OCR in Image Capture Plus from 3 to 10. (For 10 licenses)
